21 Nos
Number of tools
12000 rpm
Spindle speed
48 m/min
Traverse speed
FEATURES
- Compact machine with higher strokes
- Increased accuracy & better surface finish
- Higher tool clamping force
- Better load carrying capacity
- Ergonomically designed structure
SHORT SPECIFICATION
| Description | Unit | JV30 Neo |
|---|---|---|
| TRAVEL | ||
| X/Y/Z - Axis | mm | 500 x 400 x 320 |
| Distance between Spindle nose & Table top | mm | 150-470 |
| SPINDLE | ||
| Spindle speed | rpm | 12000 |
| Spindle bore taper | Type | BT 30 |
| Spindle motor power (Cont. / Inter.) | Kw | 3.7 / 5.5 / 7.5 |
| Max. spindle torque (Cont. / Inter.) | Nm | 17.7 / 35 / 47.8 |
| AUTOMATIC TOOL CHANGER | ||
| No. of tools | Nos | 21 |
